PAX Q25 Linux Smart PIN Pad Technical Characteristics

Please refer to the Hardware Matrix for the PAX Q25 Linux Smart PIN Pad Series to verify additional compatibility by partner.

Category	Details
Model	Q25 — Linux Smart PINpad
Operating System	Prolin
Processor	Cortex-A7
Memory	256MB Flash + 256MB DDR RAM
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	0.3MP front-facing (optional)
Display	2.4" TFT QVGA (320 × 240) pixels; touch screen optional
Comms Configurations	RS232 (base) \| Ethernet (USB 2.0) & Wi-Fi 2.4/5GHz (optional)
Battery	N/A
Printer	N/A
SIM / SAM	2 × Micro PSAM; 3rd optional
Positioning	N/A
Keys / Buttons	19 keys: Menu (Up) \| Down \| Func \| F (α) \| Enter \| Clear \| Cancel (backlighting optional)
Audio	1 × Speaker \| 1 × Microphone
Ports	Multi-functional port \| Type-C USB 2.0 (OTG, optional) \| Kensington lock
Physical	135.3 × 70.5 × 19.5 mm \| ≈210 g
Environmental	Operating: 0°C – 50°C (32°F – 122°F) Storage: −20°C – 70°C (−4°F – 158°F) Humidity: 5% – 93% non-condensing
Power Supply	Input: 100–240V AC, 50/60Hz \| Output: 5.0V DC, 1.0A
Accessories	Privacy shield \| HUB & cabling options
Certifications	PCI PTS 5.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Mastercard Contactless \| Visa payWave \| American ExpressPay \| Discover D-PAS \| Interac Flash \| J/Speedy \| UnionPay QuickPass \| Mastercard TQM \| UL \| CE \| FCC \| IC \| RoHS

Note: Looking to better understand the PAX Q25 Linux Smart PIN Pad Smart PIN pad and its capabilities? All Quick Reference Guide resources mentioned here are available for download, perfect for sharing with your team or reviewing offline to see how the PAX Q25 Linux Smart PIN Pad can streamline your payment processing experience.
