PAX A920 Max Smart Mobile Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android A920 Max Smart Mobile series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 10
Processor	Cortex-A53 Quad-Core, 1.3GHz + Secure Processor Qualcomm® Platform
Memory	System Memory: 16GB Flash + 2GB RAM Expansion: MicroSD card slot (supports up to 128GB)
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	5MP AF rear camera with flashlight
Display	6" IPS HD+ multi-touch capacitive screen \| 720 × 1440 pixels resolution
Comms Configurations	4G + Dual Band Wi-Fi + Bluetooth® 5.0
Battery	5250mAh \| 3.8V Li-ion rechargeable battery
Printer	58mm thermal printer \| 40mm paper roll diameter \| 80mm/sec print speed
SIM / SAM	1 × Micro SIM + 2 × SAM
Positioning	AGPS \| GPS \| GLONASS \| BEIDOU \| Galileo
Keys / Buttons	Power \| Volume+ \| Volume− \| Quick Scan Button
Audio	1 × Speaker \| 1 × Microphone
Ports	1 × Type-C (OTG) \| 6 Pin POGO Pin
Adapter	Input: 100–240V AC, 50/60Hz \| Output: 5.0V DC, 3.0A
Physical	165.4 × 79.5 × 63.5mm \| 445g (including battery)
Accessories	USB Cable \| Power Adapter \| Charging Base \| Shoulder Strap \| Optional: LAN Base \| Bluetooth Handset
Environmental	Operating Temperature: 0°C – 50°C (32°F – 122°F) Storage Temperature: −20°C – 70°C (−4°F – 158°F) Humidity: 5% – 93% non-condensing
Certifications	PCI PTS 6.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| UnionPay QuickPass \| JCB J/Speedy \| Interac Flash \| MasterCard TQM \| CE \| FCC \| IC \| RoHS

Note: Looking to better understand the PAX Android A920 Max Smart Mobile and its capabilities? All Quick 0Reference Guide resources mentioned here are available for download, perfect for sharing with your team or reviewing offline to see how the PAX Android A920 Max Smart Mobile can streamline your payment processing experience.
