PAX Android A800 Smart Combo Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android A800 Smart Combo Series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 10
Processor	Application CPU: Octa-core Cortex-A53, 2GHz Security CPU: ARM SC300, 32-bit RISC core (ARM v8-M), 720MHz
Memory	System Memory: 16GB eMMC + 2GB DDR Expansion: 1 microSD card slot (up to 128GB)
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	Front: 2MP fixed-focus Rear: 5MP fixed-focus
Display	5.5" IPS, 720 × 1440 pixels; capacitive multi-touch screen
Comms Configurations	4G \| Wi-Fi (2.4GHz & 5GHz) \| Bluetooth® 5.0 Optional: 4G + Wi-Fi + Ethernet + HUB
Battery	2600mAh, 3.7V Li-ion rechargeable battery
Printer	58mm thermal printer; paper roll diameter: 40mm
SIM / SAM	1 × Micro SIM + 2 × SAM (optional: 1 × Micro SIM + 1 × SAM)
Audio	1 × Speaker \| 1 × Microphone
Ports	1 × Type-C (OTG)
Adapter	Input: 100–240V AC, 50/60Hz \| Output: 5.0V DC, 1.0A
Physical	166.4 × 81 × 60.8mm \| 420g (including battery)
Environmental	Operating Temperature: 0°C – 50°C (32°F – 122°F) Storage Temperature: −20°C – 70°C (−4°F – 158°F) Relative Humidity: 10% – 90%, non-condensing
Accessories	Optional HUB \| LAN \| USB \| Charging base
Certifications	PCI PTS 6.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| Interac Flash \| MasterCard TQM \| UL \| FCC \| IC \| CE \| RoHS

Note: Looking to better understand the PAX Android A800 Smart Combo and its capabilities? All Quick 0Reference Guide resources mentioned here are available for download, perfect for sharing with your team or reviewing offline to see how the PAX Android A800 Smart Combo can streamline your payment processing experience.
