PAX A80 Smart Desktop Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android A80 Smart Desktop Series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 10
Processor	64-bit Quad-core Cortex-A series
Memory	System: 1GB DDR + 8GB eMMC Expansion: microSD card slot (up to 32GB)
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	0.2MP fixed-focus front camera
Display	4" TFT WVGA (480 × 800) pixels; multi-point capacitive touch screen
Comms Configurations	Dual-band Wi-Fi 2.4GHz/5GHz \| LAN \| Bluetooth® 5.0
Printer	58 mm thermal printer; paper roll support (high-speed)
SIM / SAM	2 × SAM
Keys / Buttons	Up \| Down \| Menu \| Func \| Cancel \| Enter
Audio	1 × Speaker \| 1 × Microphone
Ports	RJ45 LAN \| RS232 \| USB 2.0 (Micro USB OTG) \| DC power
Adapter	Input: 100–240VAC, 50/60Hz \| Output: 5.0V DC, 1.0A
Physical	~191 × 82 × 68 mm \| ~455 g
Environmental	Operating: 0°C to 50°C (32°F to 122°F) Storage: −20°C to 70°C (−4°F to 158°F) Humidity: 5% – 93% non-condensing
Optional Accessories	Cradle \| Cable \| Privacy Shield
Certifications	PCI PTS 6.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| UnionPay UICS \| Interac Flash \| MasterCard TQM \| UL \| FCC \| IC \| CE \| RoHS

Note: Looking to better understand the PAX Android A80 Smart Desktop and its capabilities? All Quick Reference Guide resources mentioned here are available for download, perfect for sharing with your team or reviewing offline to see how the PAX Android A80 Smart Desktop can streamline your payment processing experience.
