PAX Aries 8 Smart Tablet Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android Aries 8 Smart Tablet series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 7.1
Processor	Cortex®-A9 + ARM secure processor
Memory	System: 8GB eMMC + 512MB DDR Expansion: microSD card slot (up to 128GB)
Card Readers	Hybrid Chip & PIN \| Magnetic Stripe \| NFC Contactless
Cameras	Optional front-facing camera / scanner
Display	4.0" IPS WVGA (480 × 800) multi-touch capacitive screen
Comms Configurations	4G + Wi-Fi 2.4 GHz + Bluetooth® 4.2 + Ethernet
Battery	4800mAh \| 3.8V Li-ion
Printer	None
SIM / SAM	1 × Micro SIM \| 1 × Nano SIM \| 1 × SAM (other configurations available)
Positioning	GPS
Keys / Buttons	Power (ON/OFF) \| Volume+ \| Volume− \| P1 \| Cancel \| Clear \| Enter
Audio	1 × Speaker \| 1 × Microphone
Ports	1 × Type-C (OTG) \| 1 × Audio Jack \| 6-pin POGO interface
Adapter	Input: 100–240V AC, 50/60Hz \| Output: 5.0V DC, 2.0A
Physical	~162 × 72 × 19 mm \| ~270 g (including battery)
Environmental	Operating: 0°C – 50°C (32°F – 122°F) Storage: −20°C – 70°C (−4°F – 158°F) Humidity: 5% – 93% non-condensing
Accessories	Charging base \| Leather case \| Hand strap (options vary by region)
Fingerprint Reader	Optional
Certifications	PCI PTS 5.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| JCB J/Speedy \| Interac Flash \| CE \| FCC \| IC \| RoHS

Note: Looking to better understand the PAX Android Aries 8 Smart Tablet and its capabilities? All Quick 0Reference Guide resources mentioned here are available for download, perfect for sharing with your team or reviewing offline to see how the PAX Android Aries 8 Smart Tablet can streamline your payment processing experience.
