PAX A35 Integrated Smart PINpad Technical Characteristics

Please refer to the Hardware Matrix for the PAX A35 Series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 10.0
Processor	Application CPU: ARM Cortex A53 Security CPU: ARM
Memory	Flash / DDR: 8GB Flash + 1GB DDR Expansion: Optional 128GB microSD
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	Front: 0.3MP fixed-focus Optional Front: 0.5MP fixed-focus
Display	4" WVGA (480 × 800) pixels, capacitive touch screen
Communications	Wired: RS232 \| Ethernet \| USB 2.0 Wireless: Wi-Fi (2.4GHz & 5GHz) + Optional Bluetooth® (4.2/5.0)
Adapter	Input: 100–240VAC, 50Hz/60Hz \| Output: 5.0V DC, 1.0A
SIM / SAM	2 × PSAM
Keys / Buttons	13 keys: 0–9, Enter, Clear, Cancel; Back-lighting optional
Audio	1 × Speaker \| 1 × Audio Jack
Ports	Multi-functional port \| Kensington lock \| MicroSD (optional)
Physical	163.6 × 76.9 × 30.1 mm \| 260 g
Environmental	Operating Temperature: 0°C to 50°C (32°F to 122°F) Storage Temperature: −20°C to 70°C (−4°F to 158°F) Relative Humidity: 5% – 93% (non-condensing)
Accessory Options	Communication cables \| Gigabit Ethernet \| Power over Ethernet (via PoE splitter) \| Power over USB \| Pole stand
Certifications	PCI PTS 6.x SRED \| EMV L1 & L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless (UICS) \| Amex ExpressPay \| Discover D-PAS \| JCB / J-Speedy \| Interac Flash \| MasterCard TQM \| UL \| FCC \| IC \| CE \| RoHS

Note: Looking to better understand the PAX A35 Integrated PINpad and its capabilities? All Quick Reference Guide resources mentioned here are available for download, perfect for sharing with your team or reviewing offline to see how the PAX A35 Integrated PINpad can streamline your payment processing experience.
